Dual-Port, Smart AC Charging for Public & Commercial Spaces
The Etrel INCH Duo 22kW is a high-performance dual-outlet AC charging station built for high-traffic environments. With two independent Type 2 sockets, each capable of delivering up to 22 kW, it enables efficient simultaneous charging while offering advanced energy management and durable construction for long-term outdoor use.
Key Features
Dual 22 kW Charging
Two Type 2 sockets deliver up to 22 kW each, allowing two vehicles to charge at the same time with full power.Dynamic Load Management
Automatically balances power distribution to prevent overloads and reduce peak energy consumption.Smart Connectivity
Communicates via Ethernet, Wi-Fi, or 4G and supports protocols like OCPP 1.6 and Modbus TCP for seamless integration with backend systems.Interactive Touchscreen
Features a 5″ full-color LCD display for real-time status updates, instructions, and multi-language support.Flexible User Access
Supports RFID, PIN code, mobile app control, and contactless payments via NFC.Weatherproof & Vandal-Resistant
Built from stainless steel with IP54 protection and IK10 impact resistance for long-lasting outdoor reliability.Expandable Network
Supports clustering of up to 36 connectors—ideal for scaling up across commercial and fleet operations.Smart Building Integration
Compatible with energy management systems for efficient grid usage.
Technical Details
Power Output: 2 x 22 kW (3 x 32 A per outlet)
Outlets: 2 x Type 2 sockets with automatic locking
Display: 5″ full-color LCD
Protection Ratings: IP54, IK10
User Access Options: RFID, PIN code, NFC, app control
Communication: Ethernet, Wi-Fi, 4G LTE
Protocols Supported: OCPP 1.6 (JSON & SOAP), Modbus TCP
Electrical Safety: 6 mA DC sensor, Type A/B RCD, MCB (C-curve, 40A)
Optional Metering: MID-certified energy meter
Construction: Stainless steel with anti-corrosion coating
Dimensions: 134.3 cm (H) x 31.2 cm (W) x 20 cm (D)
Weight: ~38 kg
Color Options: Grey, White
